The Minn Kota Endura Max is a transom-style trolling motor that runs on a single 12V battery. You choose the shaft length (36 or 42 inch) and thrust rating, with the 55 lb versions drawing up to 50 amps. It is rated for freshwater use and weighs roughly 21 to 22 lbs depending on the configuration.
Specs at a glance
- Voltage: 12V
- Shaft length options: 36″ or 42″
- Thrust options: two ratings, up to 55 lb
- Max amp draw: 42 A (lower thrust model), 50 A (55 lb models)
- Weight: 21 lbs (36″ models), 22 lbs (42″ 55 lb)
- Dimensions: 5″ L x 47″ H x 21″ W (36″), 5″ L x 53″ H x 21″ W (42″ 55 lb)
- Use: freshwater
Good to know
- Pick shaft length based on how high your mount sits above the water: the prop needs to stay submerged when the boat rocks, and a kayak motor mount usually sits low.
- With a max draw of up to 50 amps, size your 12V battery and wiring for that load, and keep this motor in freshwater since that is what it is rated for.
KayakDIY take: A 12V trolling motor is a common way to add power to a kayak, but the mount and battery setup matter as much as the motor. For more options, see my best kayak motors guide.
